Specifications
Model: CAEL-4ZT
Total length x width x height during transportation: 4945 x 1700 x 2585 mm
Track width: 300 mm
Maximum digging depth: 3071 mm
Maximum digging height: 4816 mm
Maximum unloading height: 3382 mm
Counterweight ground clearance: 595 mm
Minimum ground clearance: 270 mm
Wheel spacing: 1750mm
Total operating: 4000 kg
Weight Bucket capacity: 0.11 m³
Engine model: Kubota 1703
Rated power: 25 HP/ 18.5 KW
Rotation speed: 12/rm
Fuel tank volume: 40L
Hydraulic all volume: 41L
Walking speed (high-low) : 3-5 KM/H
