***GENERATOR ***
– PHASE : SINGLE
– FREQUENCY : 60HZ
– VOLTAGE : AC 120V/240V
– RATED POWER :5KW
– RATED FREQUENCY : 60HZ
*** WELDING ***
-RATED DUTY CYCLE :60%
– OCV (v) : DC 75V
– CURRENT RANGE (A) : DC 50-200A
-WELDING VOLTAGE 22-28V
-WELDING ROD : 1.6-4MM
– RATED CURRENT / VOLTAGE (A/V) : 160A /DC26.4V
***ENGINE ***
-ENGINE MODEL : SC420
-MAX POWER / SPEED (RPM) : 14HP /3600RPM
-DISPLACEMENT (CC) : GAS 420CC
– START METHOD : RECOIL + ELECTRIC
– FUEL TANK : 18L
WEIGHT : 147 KG
