Description:
*Feeding System*
– *Stock Bin Volume:* 0.5m³
– *Hopper Size:* 1400*690mm
*Crushing Equipment*
– *Feed Port Size:* 400*200mm
– *Max. Feeding Size:* 150*350mm
– *Capacity:* 6-8Ton/ hr
– *Crusher Min/Max Opening:* 20-80mm
*Driving System*
– *Stage V:* Vanguard 400 (14hp)
– *Mailbox Capacity:* 6.1L
*Auxiliary Equipment*
– *Belt Conveyor:* B280*1400mm
– *Stacking Height:* 1.25m
Basic Parameters
– *Weight:* 1050kg
– *Working Size (LxWxH):* 2640*850*1540mm
– *Transportation Size:* Please contact for details
Key Features
* Efficient crushing for a variety of materials.
* Easy to transport and set up.
* Low maintenance and high durability.
* Fuel-efficient and eco-friendly Stage V engine.
* One-year warranty for parts.
