*** Overall size (unit: mm) ***
Overall length / Shipping length A : 4325/1655 mm (170/65 inch)
Overall width B : 1100mm/ 43.3 inch
upper width D : 990mm/ 39 inch
Overall height (cab roof) C : 2272mm/ 89.4 inch
Standard track shoe width F : 180mm/ 7inch
Gauge G : 920mm/ 36 inch
Minimum ground clearance H : 119mm/ 4.6 inch
Tail gyration radius I : 790mm/ 31 inch
Track grounding length J : 1050mm/ 41.3 inch
Track length K : 1545mm/ 60.8 inch
*** Performance parameters ***
Work quality (KG) : 1750KG/ 3858 LBS
Bucket capacity M^3 : 0.02
rated power : 10.2KW/2500RPM
Swing speed : 12RMP
Gradeability : 30
*** Working range (unit mm)***
Maximum excavation height a : 2580mm/ 101.5 inch
Maximum unloading height b : 1637mm/ 64.4 inch
Maximum excavation depth c : 2060mm/ 81 inch
Maximum excavation distance d : 3160mm/ 124.4 inch
Minimum radius of gyration e : 1711mm/ 67.3 inch
Maximum height f at minimum radius of gyration : 2048mm/ 80.6 inch
*** main parts ***
engine : Kubota
valve : Beifang
1 Year Warranty on all parts
2 Years Warranty on engine
Optional Adjustable Tracks: $1000
