Product Weight (lbs) 900lbs.
Cutting width 50in
Engine Briggs&Stratton
Engine Displacement 656cc
Gross Torque N/A
Cutting Height 1.5″ to 5″
Front Tire Size 13 x 5
Rear Tire Size 20 x 8
Deck Material 12 Gauge stamped Steel with 7 Gauge reinforced clutch plate
Cutting Styles Finish cut
Drive Dual hydro static drive
Cutting Speeds Infinitely variable
Max Cutting Speed 10 MPH
Battery warranty for parts 90 days
Adjustable Height (Yes/No) Yes
Adjustable Seat (Yes/No) Yes
Bag Kit Included (Yes/No) (take out?) No
Bagger Capable (Yes/No) No
Battery Recommended Battery Part# Terminal Part#
U1-3 AC 171
8229 728248
U1R-3 06069
Blade Engagement Type (PTO) Manual
Color / Finish Grey / Orange
Commercial Duty (Yes/No) No
Commercial Warranty (Yes/No) No
Cup Holder Yes
Cutting Width (in) 50 in.
Deck Gauge 12-Guage Stamped Steel
Discharge Location Side
Engine Displacement (cc) 764cc
Engine Horsepower (hp) 20HP
Engine Make Briggs&Stratton
Engine Oil Included (Yes/No) Yes
Engine Style (Single Cylinder, V-Twin) V-Twin
Engine Torque (ft-lbs) N/A
Frame Material Steel
Front Axle Material Steel
Front Wheel Size 13 x 5 in.
Fuel Tank Capacity (gal) 4 gal
Fuel Type Gasoline
Grease Fittings Included Yes
Hazardous Material No
Headlights (Yes/No) NO
Hour Meter (Yes/No) Yes
Housing Material Steel
Instructions / Assembly Required (Yes/No) No
Manual Available Yes
Maximum Cutting Height (in) 5 in.
Maximum Forward Speed (mph) 10 MPH
Maximum Reverse Speed (mph) 6.5 mph
Minimum Cutting Height (in) 1.5 in.
Mower Deck Width (in) 48 in.
Mulch Kit included (Yes/No) YES
Mulching Avabile (Yes/No) YES
Number Of Anti-Scalp Wheels 2
Number of Blades 3
Number of boxes shipped to customer 1
Number of Cutting Positions 8
Number Of Cylinders 2
Number of Handle Position Adjustments N/A
Number of Seat Positions 11
Oil Capacity 1.8 qt.
Oil Filter Type Spin on canister
Operator Controlled Mow-in-Reverse (Yes/No) Yes
Package Contents mower and manual
Package Dimensions 90x54x79
Palletized Yes
Parts List Available Yes
Product Dimensions 75 x 54 x 72
Rear Axle Diameter (in) 1.2 in.
Rear Wheel Size 20 x 8 in.
Recommended Oil 10W-30
Recommended Safety Equipment Ear and eye protection, closed toe shoes, long pants
Rust Resistant No
Seat Type High back
Single Lever Height Adjustment (Yes/No) Yes
Size Of Deck Wheels 3 in.
Snow Blade Capable No
Snow Thrower No
Speed Control (Single/Variable) Variable
Spin-On Oil Filter Yes
Terrain Type (Flat, Flat w/obstacles, hilly) Flat with Obstacles
Transmission Type Dual hydrostatic
Turning Radius (in) 0 in.
Type Of Lubrication System Full pressure
