DUAL A/C Machine recovery for both R134A and R1234YF

Upgrade your automotive air conditioning service with this advanced Automatic A/C Refrigerant Recovery, Recycling, and Charging Machine. Designed for professional workshops and service centers, this unit provides efficient refrigerant recovery, precise charging, vacuum operations, and oil management for modern vehicle air conditioning systems.

Built with high-precision load cells, powerful vacuum performance, and dual refrigerant tanks, this machine ensures accurate servicing for both R134a and R1234yf refrigerant systems.

Key Features

✅ Dual Refrigerant Compatibility
Supports both R134a and R1234yf refrigerants with separate 12L storage tanks for safe and efficient operation.

✅ High Precision Charging System
Equipped with advanced load cell technology for accurate refrigerant and oil measurement:

• Refrigerant load cell precision: 30kg ±10g
• Oil bottle load cell precision: 6kg ±5g

✅ Powerful Vacuum Performance

• Vacuum pump capacity: 4.5 CFM
• Ultimate vacuum: 3 Pa
• Compressor displacement: 12.12cc

✅ Efficient Oil Management System
Includes:

• New oil bottles: 30ml × 2 pcs (PAG & POE)
• Used oil bottle capacity: 500ml

✅ Easy Operation & Clear Display

• LCD display: 240 × 128
• User-friendly interface for simple operation and monitoring

  Product Specifications


  Specification	Details
  Voltage	AC 110V / 60Hz
  Current	8A / 12A
  Compressor	12.12cc
  Vacuum Pump	4.5 CFM, 3 Pa
  Refrigerant Tanks	12L × 2 (R134a & R1234yf)
  New Oil Bottle	30ml × 2 (PAG, POE)
  Used Oil Bottle	500ml
  Refrigerant Load Cell Accuracy	30kg ±10g
  Oil Load Cell Accuracy	6kg ±5g
  Maximum Working Pressure	20 Bar
  LCD Screen	240 × 128
  Machine Dimensions	670 × 730 × 1445 mm
  Gross Weight	128 kg
